(Diode test circuit model.) |
|||
| Line 1: | Line 1: | ||
| - | Diode test circuit model. | + | Diode test circuit model from Convex Optimization & Euclidean Distance Geometry, Chapter 8.1. |
| + | (a) Large signal diode model: | ||
| + | 1) junction capacitance C_j is small enough to ignore for audio applications, | ||
| + | 2) diffusion capacitance C_d whose polarization (+) indicates significant capacitance only for positive bias voltage v_d, | ||
| + | 3) static semiconductor & contact resistivity R_d a.k.a parasitic resistivity. | ||
| + | (b) Figure 211b unbalancing and consolidation to help explain high median impedance of diffusion capacitor. | ||
| + | [[https://www.convexoptimization.com/TOOLS/Sedra.pdf PSPICE DEVICE MODELS & SIMULATION]] | ||
Revision as of 22:12, 16 January 2025
Diode test circuit model from Convex Optimization & Euclidean Distance Geometry, Chapter 8.1. (a) Large signal diode model: 1) junction capacitance C_j is small enough to ignore for audio applications, 2) diffusion capacitance C_d whose polarization (+) indicates significant capacitance only for positive bias voltage v_d, 3) static semiconductor & contact resistivity R_d a.k.a parasitic resistivity. (b) Figure 211b unbalancing and consolidation to help explain high median impedance of diffusion capacitor. [PSPICE DEVICE MODELS & SIMULATION]
